1000 GPD RO Water Purifier Installation & Service In Oman-Muscat Water

Model: -1000G

MUSCAT WATER series consists of devices that are completely ready for use. Muscat water Designed to produce low dissolved solids water from tap or well water, these Small Commercial & Industrial RO system. use high efficiency reverse osmosis membranes. Muscat water systems are designed to work at pressures of 200-400 psi for higher TDS water and use reverse osmosis membranes. The RO membranes offer higher salt removal and the higher operating pressure overcomes the loss of membrane flow due to higher TDS level.

Features:

• S.steel frame (Control box-option)
• 20" Prefilters x 3
• S.steel Membrane vessel
• 4" x 21" membrane
• Inlet & Flush Solenoid Valve
• Gauge & Flow meter
• 240gph vane pump & 1hp motor
• Auto Flush Control & TDS detector
• Pressure Regulator
• Anti-scalent device
• Electricity consumption: 764W
• Shipping Dimension & weight: 80X50X116cm 60kgs

Description

Muscat water 1000 GPD Reverse Osmosis Water Treatment Plant

Specification

• Production Capacity: 1000Gallon Per Day
• Salt Rejection: 96-98%
• Recovery Rate: 50-60%
• Connection: 3/8" Feed, 1/2"Permeate, 1/2"Concentrate

Features

• Computer Control Panel
• Low-Pressure Monitoring Alarm
• Dual TDS Monitoring
• Feed Flush
• Tank Level Input
• Vertical Multi-Stage Stainless Steel Booster Pump
• Feed Solenoid Valve with Electronic Bypass
• Feed Low-Pressure Switch
• Pump High-Pressure Switch
• Pre-Filter 0-100 psi Panel Mounted Glycerin Filled Gauges
• Pump Discharge and Concentrate 0-600 psi Panel Mounted Glycerin Filled Gauges
• 5 Micron Sediment Filter
• O-Ring & Heavy-Duty Filter Housing
• Low Energy Membrane Elements
• Stainless Steel Membrane Housings-450 psi
• Clean-in-place (CIP) Ports
• High-Pressure Stainless Steel Tubing and Fittings
